Well this is a new one for me.....and I've been in this design field for 30+ years. Looking at your elevation it appears you're using overlay doors. Meaning the door is outside of the the frame front......I'm guessing your cabinet maker is seeking an elevation without the doors so he can see the frame fronts and get a better look at the configuration and the size of the cabinet units. While I know of many cabinet craftsmen who could take your sketch and run with it.......one thing I always tell young designers is to draw with a thought in your mind as to how is the craftsman or contractor going to build this either in the shop or in the field. I would suggest that you download Google Sketchup (it's free) and easy to learn how to use it. Then I would suggest that you actually build your cabinets piece by piece just as you would if you were building them in the shop Start with the base, add the frame front the sides, back and supports. Then you can add the drawer fronts and cabinet doors...........if you get really into it you could build the actually drawer units individually....... I do this for every custom design home for clients. Cabinet makers love it, because I'm basically giving them a shop drawing, complete with dimensions and I'm confident that design fits in the intended space down to the width of spacers I need. I also give this package to the framing contractor so he know just how exact I expect his framing for the space to be.

thanks for your prompt reply Amitji I will definitely talk with the designer and make the necessary corrections. if possible plz suggest where should I keep the pooja room. As per vastu it should be in the NE direction. In my plan it comes just before the window in the living room. sir, I am not able to adjust the pooja room. plz provide the suggestion thanks

Hello Pravin, Instead of suggestions we do have some questions, GF 1- Do you need a bath that is 10 ft long? Its too close to your dining. GF 2- Do you need a balcony in GF. What is the purpose? Given the space crunch it may be worthwhile to reduce the balcony space. The bath is located at the far end and may be inconvenient for guests to walk through the entire home for a visit. FF For a 3 BHK you have XXL size 3 balconies and one Terrace! May be you need that much open space, just give it a thought. Kitchen is larger than most of the rooms. Do you need that size kitchen or can you swap it with adjoining room. Thanks, Amit Cornerstone Designs, Bangalore.

Hi, as per vasthu, site west side 1. west side road and 45' width 2. north and south 60' 3. ground flore 2 bed room, 1 bedroom master attached bath 4. front car parking portico 5. first flore 2 bed with attach and bolcony 6. south west part small gate for two wheeler parking
