duplicate post.

Manipalgoyal: I like your basic plan. It is well thought out....What does the top floor look like? The only thing that I would do differently from my very "Western" perspective would be to move the rear right bedroom upstairs and open up the back courtyard to the kitchen area. I would create a "great room / kitchen area with doors that open both to the front courtyard and to the back. This allows for good cross ventilation to help keep the house cool and comfortable on a hot day. It also provides easy access to the rear yard area without having to walk through a bedroom. Now all of the precious outdoor space is easy to use. The other element that I would introduce would be an atrium (or an opening in the floor) all the way up to the second floor with openable windows high up on the second floor to allow hot air to escape to the top of the house and out (since hot air rises) This is called the "chimney effect" and is another way to keep the house well ventilated. Of course this is how it has been done in hot climate countries for years, so you might be familiar with this technique already. Even if you don't change it, your floor plan is very nicely laid out. I would be happy to help you answer any additional questions that you might have. I do have a few questions for you: 1. Where is the laundry room? Is it in the storage space? This does seem a little narrow. How wide is it? You might want to work on how this space actually lays out. Is there a sink in this space too? 2. Why do you have such small openings to the outside from the drawing room and the rear bedrooms? Are they doors or windows? Wouldn't you wnat a door with an openable window with a screen adjacent so that you could have ventilation at night without having the door open? 3. How will you lay out the kitchen? Who is doing the cooking in your household? Is cooking a family event or is it done by a helper? You either want a bigger more open kitchen (Western design) or a more private kitchen (Asian design) Or a combination of both.......To me this is the most important part of the house where the family gathers and hangs out..... I would love to hear back from you. Christine Lampert

There are a number of factors that will dictate the design of your house. The first step is to visit the local building department to find out the restrictions for your lot. Do you need to set back the house from the property lines? Is there a maximum site coverage that the jurisdiction allows? For example, in San Clemente, California you can only cover 50% of your lot with your house. Do you need to include parking on your site? Most cities in the USA require 2 parking spaces on the site. The shape of the lot and the access to the lot as well as any potential views, and even the location of the sun and the prevailing winds will impact your design. Find out the information that I listed above and post it with a dimensioned site plan and you may get some great design suggestions. Another option is to look for a local architect using houzz.com.......... Good luck and have fun........

Hi, Do you want to demolish the old house completely? You haven't shown the staircase in your new plan. The kitchen size mentioned by you is too big. I think 10x15 means kitchen and dining space both. For any help you can contact me on 7838154046 or write to me on pkassociates8@gmail.com.
