Hi Adrain, Again thanks for showing interest in my post. I have highlighted my plot on a piece of paper. There are two parts marked as L and R. As I told u earlier i am making on half of the plot size available to me. Either I can make on L or I can make it on R. There are no such restrictions on material to be used but in India we don't used wood to make outer walls. General practice here is to use bricks and cement. I am adding to photographs one is a piece of paper highlighting my part of plot and the other is the google map pic. I cuing highlight in tht but I have marked it with red my side of plot. If u can compare both the pics u might be able to figure out the whole idea of the place. As far as the servant room is concerned it is a small room with kitchen and sedate bathroom attacked to the room. It's generally very small and have no access to the main house. To give u an example the servant room may be of the size 10 feet by 15 feet which includes a small kitchen and bathroom including the room too. Shaleen

OnePlan has a point -- people are notoriously unaware when attention is elsewhere -- like getting to the front door. Laying pavers in a different color/pattern/size (pick an option that appeals to you) that will be the same level as the remaining pavers would give you the distinctive path. Shame to cover the pavers; can they be removed without destroying? Alternative that comes to mind is to create a barrier along that line. A railing mounting on the pavers either 3' high or 6' high -- pick your medium. metal posts w/railing. glass panels in a framwork. shoji screens. colorful curtains hung from above. A photo from further back, showing the front of the house would help suggestions.

Manipalgoyal: I like your basic plan. It is well thought out....What does the top floor look like? The only thing that I would do differently from my very "Western" perspective would be to move the rear right bedroom upstairs and open up the back courtyard to the kitchen area. I would create a "great room / kitchen area with doors that open both to the front courtyard and to the back. This allows for good cross ventilation to help keep the house cool and comfortable on a hot day. It also provides easy access to the rear yard area without having to walk through a bedroom. Now all of the precious outdoor space is easy to use. The other element that I would introduce would be an atrium (or an opening in the floor) all the way up to the second floor with openable windows high up on the second floor to allow hot air to escape to the top of the house and out (since hot air rises) This is called the "chimney effect" and is another way to keep the house well ventilated. Of course this is how it has been done in hot climate countries for years, so you might be familiar with this technique already. Even if you don't change it, your floor plan is very nicely laid out. I would be happy to help you answer any additional questions that you might have. I do have a few questions for you: 1. Where is the laundry room? Is it in the storage space? This does seem a little narrow. How wide is it? You might want to work on how this space actually lays out. Is there a sink in this space too? 2. Why do you have such small openings to the outside from the drawing room and the rear bedrooms? Are they doors or windows? Wouldn't you wnat a door with an openable window with a screen adjacent so that you could have ventilation at night without having the door open? 3. How will you lay out the kitchen? Who is doing the cooking in your household? Is cooking a family event or is it done by a helper? You either want a bigger more open kitchen (Western design) or a more private kitchen (Asian design) Or a combination of both.......To me this is the most important part of the house where the family gathers and hangs out..... I would love to hear back from you. Christine Lampert
